One component, nanosilica filled, dual cure system with UV and heat curing mechanisms passes ISO 10993-5 for cytotoxicity and USP Class VI

Key Features

  • Low viscosity
  • Minimal shrinkage upon curing
  • Superb optical clarity
  • Cures at 80°C in shadowed out areas

Product Description

Master Bond UV22DC80-1Med is a nanosilica filled, dual cure epoxy based system. It is formulated to cure readily upon exposure to UV light and most importantly it will cross-link in shadowed out areas with the addition of heat. The logic in developing this kind of product is that UV curables will cross-link rapidly and thoroughly upon exposure to the light, but it will not cure in areas where the material is not exposed to the light. Having a dual cure mechanism allows those areas not exposed to the light being curable with the addition of heat. The thermal part of the cure is achieved at a user friendly 80°C (particularly when working with plastics). Dual cure systems are particularly useful for rapidly fixturing parts with the UV portion of the cure and then finishing the process by heating.

This lower viscosity system features a cationic cure mechanism (for the UV portion). This combined with being a nano filled system confers an exceptionally low shrinkage and outstanding dimensional stability. UV22DC80-1Med is not oxygen inhibited. After polymerizing, it has many advantageous properties. It bonds well to a wide variety of substrates including metals, glass, ceramics and most plastics. UV22DC80-1Med has very good chemical resistance to many acids, bases, fuels and solvents. It is a superb electrical insulator, also it is able to withstand rigorous thermal cycling. The service temperature range is -60°F to +350°F.

Straight UV curing can be accomplished for thicknesses of 0.01-0.02 inches in seconds using UV light at 365 nm with 20-40 milliwatts/cm2 of energy. Faster cures can be achieved at higher energy outputs. Areas not cured because of shadowing can be cured at 80°C for 40-60 minutes. In addition, post curing at 125-150°C for 15-30 minutes can increase the glass transition temperature (Tg) from 90°C achieved by straight UV curing to over 125°C. The combination of an 80°C secondary cure and the presence of a nano filler imparts very special properties to this compound. The ability to initiate curing with a UV light source and complete it with heat opens new horizons for the use of UV22DC80-1Med in high tech applications particularly with medical devices.

Product Advantages

  • One component system; no mixing needed
  • Dual cure UV and heat at 80°C
  • No oxygen inhibition
  • Excellent physical strength properties
  • Nano filled--high dimensional stability, resists abrasion
  • Passes ISO 10993-5 and USP Class VI

Industrial Certifications

USP Class VI Medical

ISO 10993-5 for Cytotoxicity

Meets EU Directive 2015/863





UV22DC80-1Med is available is various sizes and units to accommodate customer's needs.
