Two component, toughened epoxy for bonding and sealing with high temperature resistance

Key Features

  • Easy processing
  • Paste consistency
  • NASA low outgassing
  • Withstands 1,000 hours 85°C/85% RH

Product Description

Master Bond epoxy system Supreme 33ND offers a highly attractive blend of superb physical strength properties, outstanding temperature resistance and easy handling along with a non-drip viscosity. The mix ratio is 100 to 70 by weight or 1 to 1 by volume. This non-flowable system bonds well to many different kinds of substrates including metals, composites, glass, ceramics, rubbers and plastics. t is cryogenically serviceable and has a wide temperature range extending from 4K up to +425°F. It is highly resistant to aggressive thermal cycling. It also has very good chemical resistance to water, fuels, hydraulics as well as many acids and bases. It is a solid electrical insulator with superior retention of those properties at elevated temperatures. Supreme 33ND has a number of curing options including cure schedules at room temperature, with heat or a combination of the two. The optimum cure is overnight at room temperature followed by a few hours at 150-200°F. Part A is colored gray and Part B is amber. Its exceptional dimensional stability and minimal shrinkage upon curing enables it to be an excellent choice for applications in the aerospace, electronic and specialty OEM industries.

Product Advantages

  • Forgiving mix ratios: 100:70 by weight or 1:1 by volume
  • Bonds well to a wide variety of substrates
  • Cryogenically serviceable
  • Passes NASA low outgassing
  • Withstands 1,000 hours 85°C/85% RH

Industrial Certifications


ASTM E595 Compliant

1,000 Hours at 85°C/85% RH

Meets EU Directive 2015/863

Packaging


Cans

Pails

Supreme 33ND is available is various sizes and units to accommodate customer's needs.
