One component, nanosilica filled LED curable system

Key Features

  • Meets ISO 10993-5 for cytotoxicity
  • Fast cure with appropriate LED light
  • Resists sterilization
  • Not oxygen inhibited
  • Can cure up to 1/8 inch thick
  • Outstanding optical clarity

Product Description

Master Bond LED405Med is a one part system that cures upon exposure to a 405 nm LED light without requiring a UV light source. It will cure without any oxygen inhibition. Its most special feature is that its main constituent is a nanofilled resin. This results in lower shrinkage upon curing and greater dimensional stability. By using LED light and not UV, it is intrinsically less hazardous and more user friendly.

Master Bond LED405Med requires no mixing and cures rapidly upon exposure to 405 nm LED light. The speed of cure depends upon the intensity of the light source, the thickness of the layer, and the distance of the light source from the material being cured. Realistically, the light intensity should be 1-4 watts/cm2. Master Bond strongly advises end users to consult with their LED light provider in order to choose the best light source.

LED405Med will typically cure in 30-45 seconds in thinner sections, while thicker sections will take longer to cure. LED405Med bonds well to a wide variety of substrates including metals, plastics and glass. It is a superior electrical insulator and is resistant to water, several acids and bases, as well as oils and fuels. LED405Med resists many sterilization methods such as gamma, EtO and radiation. It has a particular affinity for acrylics, polycarbonates, and glass.

Product Advantages

  • One component system needs no mixing
  • Cures by LED light, UV light not required
  • Nanofilled system
  • Unsurpassed low shrinkage upon curing
  • Reasonably good physical strength properties
  • Superb dimensional stability

Industrial Certifications

ISO 10993-5 for Cytotoxicity

Meets EU Directive 2015/863




LED405Med is available is various sizes and units to accommodate customer's needs.

Visual Media

How Do You Use an LED Curing Adhesive?

LED curable adhesive systems offer safe and rapid cures upon exposure to an LED light source. Learn how to properly apply and cure an LED curable adhesive system using a portable LED light source in this demonstration video.
