Two component, optically clear epoxy for medical device applications

Key Features

  • Low viscosity
  • Fast curing, even in thin sections
  • Good sterilization resistance
  • Passes ISO 10993-5

Product Description

Master Bond EP30-4Med is an optically clear, two component epoxy system for high performance bonding, coating, sealing and casting. The mix ratio is a forgiving two to one by weight. Upon mixing, this low viscosity system cures rapidly at room temperature and the cure can be accelerated with heat. In fact, it is a relatively fast setting system, and in some cases, depending upon the application and the substrates, fixtures often can be removed in 15-25 minutes. EP30-4Med contains no solvents or diluents and has very low shrinkage upon curing.

EP30-4Med can be easily applied with a gun dispenser and offers a convenient 2:1 mix ratio. Its low viscosity makes it ideal for small potting and encapsulation applications.

The compound cures quickly, even in thin sections with a set up time of about 30 minutes depending on application specifics. EP30-4Med offers a working life of 10-15 minutes per 100 gram batch.

EP30-4Med is a good adhesive and bonds well to a variety of substrates including metals, composites, ceramics, glass and many rubbers and plastics. It offers superb electrical insulation properties and can be used for small castings and pottings. This system features good chemical resistance to water, most liquid sterilants and EtO sterilization. The color of Parts A and B is clear. EP30-4Med also can be used for coating applications, particularly when a clear coating is desirable. It is serviceable over the wide temperature range of -60°F to +250°F. It is most noteworthy for its fast curing and optical clarity. EP30-4Med would be used primarily in medical device manufacturing where an optically clear, low viscosity, fast curing epoxy is desirable.

Product Advantages

  • Easy to use mix ratio, two to one by weight
  • Fast curing, even in thin sections
  • Optically clear
  • Low viscosity, well suited for potting and encapsulation
  • Passes ISO 10993-5

Industrial Certifications

ISO 10993-5 for Cytotoxicity

Meets EU Directive 2015/863



Gun Applicator


EP30-4Med is available is various sizes and units to accommodate customer's needs.
